Description
Simple Angle Glass Tube Liquid Level Gauge
The ZCG-05 tube type level gauge is a new type of level gauge that integrates the multiple advantages of a glass tube level
gauge, a plate type level gauge, and a boiler water level gauge. (It overcomes the weaknesses of the original glass tube level
gauge that it is afraid of breaking, not strong, unsafe, not pressure resistant, unclear, and low in temperature.) It can replace
the glass plate level gauge to a certain extent, and is better than the liquid level gauge with the same characteristics.
But meter is low in price.
Features
● Intuitive instrument
● Simple structure and convenient maintenance
Main Specifications
● Measuring range: 100, 150, 200, 250, 300
● The working pressure of the measured medium: 1.6MPa, 2.5, 4.0
● Working temperature of tested medium: -10℃～＋200℃
● Interface thread: G3/8 or M16
Note: The tube level gauges of the above specifications can be designed according to the user's requirements.
The main technical indicators of the single interface small glass tube level gauge
1 Measuring range: 100, 150, 200, 250, 300 (MM)
2 Working pressure of measured medium: 0.6Mpa, 1.0MPa
3 Working temperature of tested medium: -10℃～＋200℃
4 Interface thread: G3/8, G1/2, G3/4, M16*1.5, M20*1.5 (other specifications can be customized)
5 Main body material: stainless steel 304, 316 single interface small glass tube level gauge features
